SZ Series Conical Twin Screw Extruder Gearbox

Kufotokozera Kwachidule:

Ma gearbox a SZ a conical twin-screw extruder ndi gawo lapadera loyendetsa lomwe limayenderana ndi mapasa a conical-screw rod extruder. Amakhala ndi magawo awiri, omwe ndi, bokosi lochepetsera ndi bokosi logawa. Pambuyo pochepetsa liwiro ndikuwonjezera torque ya injiniyo, imatulutsa mphamvu yopangira ...

Tsatanetsatane wa Zamalonda

Zolemba Zamalonda

Zambiri Zoyambira

Mphamvu zolowetsa 18.5KW ~ 110KW
Chophimba Dia 45-92 mm
Kutulutsa torque ya shaft imodzi 1972N · m ~ 13130N · m
Liwiro lolowetsa 1500 RPM
Linanena bungwe liwiro Zotengera chiŵerengero
Zida zamagetsi 20CrMnTi chitsulo chochepa cha carbon alloy
Zida zapanyumba Kuponya chitsulo
Gear Processing CNC Akupera
Mtundu wa ma bearings C&U , NXZ , ZHJ, ZWZ, LYC, HRB, NSK,FAG, etc.
Chizindikiro chamafuta amafuta FAG, NAK, etc
Kuuma kwa magiya pamwamba HRC54~62
Kulondola kwa zida Gulu 6
Kutentha mankhwala Carburizing, Kuthetsa
Zotulutsa Kutulutsa kwa spline shaft
Lowetsani Shaft Yokhazikika

Kufotokozera Zamalonda
SZ mndandanda wa gearbox wa conical twin-screw extruder ndi gawo lapadera loyendetsa lomwe limafanana ndi conical twin-screw rod extruder. Amakhala ndi magawo awiri, omwe ndi, bokosi lochepetsera ndi bokosi logawa. Ikachepetsa liwiro komanso kuchuluka kwa ma torque agalimoto, imatulutsa mphamvu yopangira bokosi logawa, kenako imayendetsa ma shafts awiri (makona ophatikizidwa ndi ofanana ndi amapasa - ndodo) kudzera pamagiya ang'onoang'ono ozungulira okhala ndi 1: 1, motero kuyendetsa ndodo zomangira kuzungulira kunja ndi njira zosiyanasiyana.

Product Mbali
1.Pali involute cylindrical gearbox, yomwe deta ndi mawonekedwe amapangidwa bwino ndi kompyuta.
2.The magiya amapangidwa pamwamba-ubwino mkulu mphamvu otsika mpweya aloyi chitsulo pambuyo mpweya olowera, kuzimitsa ndi mano akupera. Ili ndi kuuma kwakukulu pamano, kunyamula kwakukulu, phokoso laling'ono, kugwira ntchito bwino komanso kuyendetsa bwino kwambiri.
3.Zakuthupi za bokosi logawa ndi nodular graphite kuponyera chitsulo ndi magiya ali ndi mkulu-mano apansi amphamvu, momwe njoka-mipope yamadzi ozizira yozungulira imagawidwa.
4.Kuthamanga kwambiri kwa gearbox nthawi zambiri sikuposa 1500 rpm.
5.Kutentha kwa malo ogwirira ntchito ndi -10℃-45 ℃.Pamene kutentha kuli kochepa kuposa 0℃, mafuta odzola ayenera kutenthedwa mpaka + 10℃ asanayambe.

Technical Parameter

Mtundu Chingwe Dia (mm) Kuthamanga kwapakati Liwiro Lolowetsa (r/mphindi) Mphamvu Yolowetsa (KW)
SZ45 45 33.48 1500 18.5
SZ50 50 39.68 1500 22
SZ55 55 40.00 1500 30
SZ65 65 38.23 1500 37
SZ80 80 38.77 1500 55
SZ92 92 40.47 1500 110


Kugwiritsa ntchito
SZ mndandanda gearbox chimagwiritsidwa ntchito pulasitiki conical amapasa - scruder extruders.



FAQ

Q: Momwe mungasankhire a gearbox ndigear speed reducer?

A: Mutha kuloza ku kabukhu lathu kuti musankhe mtundu wazinthu kapena titha kupangiranso mtundu ndi mawonekedwe mutapereka mphamvu zamagalimoto zofunika, liwiro lotulutsa ndi liwiro, ndi zina zambiri.

Q: Tingatsimikizire bwanjimankhwalakhalidwe?
A: Tili ndi ndondomeko yokhazikika yoyendetsera ntchito ndikuyesa gawo lililonse musanapereke.Makina athu ochepetsera ma gearbox adzachitanso mayeso ofananirako atatha kukhazikitsa, ndikupereka lipoti loyesa. Kulongedza kwathu kuli mumilandu yamatabwa makamaka kuti titumize kunja kuti titsimikizire zamayendedwe.
Q: Chifukwa chiyani ndimasankha kampani yanu?
A: a) Ndife m'modzi mwa otsogola opanga ndi kutumiza kunja zida zotumizira zida.
b) Kampani yathu yapanga zida zamagiya kwazaka pafupifupi 20 ndikudziwa zambirindi zamakono zamakono.
c) Titha kupereka ntchito yabwino kwambiri komanso yabwino kwambiri yokhala ndi mitengo yampikisano pazinthu.

Q: Ndi chiyaniwanu MOQ ndimawu amalipiro?

A:MOQ ndi gawo limodzi.T/T ndi L/C ndi zovomerezeka,ndipo mawu ena amathanso kukambirana.

Q: Kodi mungapereke zolemba zoyenera za katundu?

A:Inde, titha kupereka zolemba zambiri kuphatikiza buku la opareshoni, lipoti loyesa, lipoti loyendera bwino, inshuwaransi yotumiza, satifiketi yochokera, mndandanda wazolongedza, invoice yamalonda, bili yonyamula ndi zikalata zina zotumiza kunja.
